MFI Apple Find My Air Card

Thanks to our cold lamination technology, here comes a ultra-thin rechargeable Bluetooth find my iPhone and iPad Card Tracker to well fit your keys, wallet, luggage, backpack etc., especially for your leisure travel such as camping, touring, trekking

Product Details

Product Parameters



Activate Lost Mode to ask Apple Devices everywhere to find your item.
- Quick and easy setup.
- Guarantee your essentials secured all the time.
- Slim and water resistant
- Convenient Charging way.
- Locate Nearby Items with Find My.

Thanks to our cold lamination technology, here comes a ultra-thin rechargeable Bluetooth find my iPhone and iPad Card Tracker to well fit your keys, wallet, luggage, backpack etc., especially for your leisure travel such as camping, touring, trekking (backpacking)





【Slim Smart Card】: Just 1.5-1.6mm thin, credit card size, perfectly attach with your wallet, ID card, luggage tag, passports, electronic devices and more in a convenient way.
【Wireless/Wired Charging】: Based on economical and easy chargeable way, a full charge lasts up to 4-5 months, with color LED indicator.
【Find Nearby】: Within a Bluetooth range up to 164 feet and compatible with Apple devices, it triggers the built-in buzzer to locate your belongings via your phone by using Find My network. ( Android devices are not supported.)
【Left-Behind Remind】: If smart track card is out of Bluetooth range, your iPhone will receive a notification reminder about your item last location before disconnection plus the most recent location on the Find My app without any subscription fees.
【Lost Mode】: Activate Lost Mode for your find my wallet tracker to locate your belongings with the help of Apple devices in the Find My network around the world. When it’s detected, a notification could be automatically received.
【Share This Item】: New function for iOS 17 by sharing items in Find My with up to 5 borrowers which allows them to see the item's location on a map.
【Privacy Protection】: Guaranteed Data Security based on Apple’s powerful service and encryption.
【IP67 Waterproof & Dust Resistant】: With IP67 Waterproof & Dust Resistant, it is perfect for outdoor activities and workshops.









Electrical Parameters
Battery nominal voltage 3.7V
Nominal Capacity 100mAH
Average Working Current 20uA
Charging Time 1.5~2 hours
Charging Current ≦ 100mA
Service Life 300 cycles
Sleep Standby Time >1 year
Shutdown Voltage 2.5V
Size 47.5*33.3*3.3mm
85.5*54*1.6mm



Protocol Specifications
Wireless Charging Protocol WPC wireless charging latest Qi standard V1.2
  NFC Protocol ISO/IEC-14443 (Optional)
  Bluetooth Protocol Bluetooth V5.0

Working Frequency
RFID Frequency 13.56 MHZ(Optional)
  Bluetooth 2.4GHZ
  Wireless Rechargeable 127KHZ
  Bluetooth RF Parameters Transmit Power: -20 ~4dBm
  Receiver Sensitivity -96dBm


How to use compatible ble smart card with Apple’s Find My?
Binding Findeasy with your device
Device power-on: Press and hold the card button for 5 seconds, it will ring and turn on.
Bind the device: Open Apple's built-in "Find My" APP.
Hold the device near your iPhone, tap the Items tab, select “Add New Item”, and tap Other Supported Items. For devices showing: USC-FY10X, tap Connect.
Fill in "Custom name" to name your device and choose an emoji.
Agree to register the device to your Apple ID. Tap Done to bind successfully.
Also, don’t forget to secure your Apple ID with two-factor authentication and turn your Bluetooth on.

Enable "Lost Mode"
Open Apple's built-in Find My app, tap "Items" at the bottom, then choose the name of the item.
Under "Lost Mode", click "Enable".
Follow the on-screen instructions and click "Continue" to enter your phone number or email address.
Click "Next" to check the information, and then click "Enable" again to complete the setup.

Delete the device
Open Apple's built-in Find My app, tap "Items" at the bottom of the screen, and choose the name of the item.
Find “ Remove Item” at the bottom of the list, tap Remove to finish.
Note: After deleting the device, the device will sound and the indicator will flash 6 times, and the device will not power off and be in pairing mode.
If there is no re-pairing within 10 minutes, the device will leave the pairing state, and cannot be paired with the app.
If you need to pair a device, you need to tap the card button once, the device will ring and flash the light once. The device enters the pairing state and can be re-paired with the app.




Other Applications:
Personnel Positioning
Manufacturing: Trackers help to reduce the amount of time they spend searching for materials, tools, and equipment.
Hospitals or Medical Centers: Trackers help to locate medical equipment to divert the flow of people, reduce waiting times, and increase equipment utilization.
Logistics: Trackers help to grasp the location of goods, shorten delivery times, monitor the transportation process and understand the status of transportation.
Education: Trackers help to track school assets such as lab equipment, library books, laptops etc.
Farms: Trackers help to track and monitor livestock, track harvested crops and their location in various storage facilities, manage the location of agricultural machinery equipment.
Rental Companies: Trackers help to keep track of rental projects in and out of your jurisdiction.
